IDEAL imax plus F80 User Manual

27
- Installation & Servicing
INSTALLATION
By pressing the mode key twice, DATA mode is displayed. In this mode it is possible to read information on the operation of the boiler.
30 DATA MODE
Press Display Press Display Description Unit
Local flow temperature, NTC1 ºC
Local return temperature, NTC2 ºC
Module 1 fan speed setpoint rpm
Module 1 actual fan speed rpm
Data Accessible only to the Installer by previously entering the service code. Data relevant to individual burners.
Local flow temperature, NTC1 ºC
Local return temperature, NTC2 ºC
Module 2 fan speed set point rpm
Module 2 actual fan speed rpm
Local flow temperature, NTC1 ºC
Local return temperature, NTC2 ºC
Module 3 fan speed set point rpm
Module 3 actual fan speed rpm
Local flow temperature, NTC1 ºC
Local return temperature, NTC2 ºC
Module 4 fan speed set point rpm
Module 4 actual fan speed rpm
Local flow temperature, NTC1 ºC
Local return temperature, NTC2 ºC
Module 5 fan speed set point rpm
Module 5 actual fan speed rpm
STEP
B U R 1
STORE
1 . X X
2 . X X
X X X X
X X X X
STEP
B U R 2
STORE
1 . X X
2 . X X
X X X X
X X X X
STEP
B U R 3
STORE
1 . X X
2 . X X
X X X X
X X X X
STEP
B U R 4
STORE
1 . X X
2 . X X
X X X X
X X X X
STEP
B U R 5
STORE
1 . X X
2 . X X
X X X X
X X X X
Press Display Description Unit
Global flow temperature ºC
Global return temperature ºC
DHW temperature ºC
Outside temperature ºC
N/A ºC
Flow temperature set point ºC
Fan speed set point rpm
Output calculated in % (100% per module) %
Data Accessible to Installer and User. Data relevant to the whole boiler.
STORE
T O T
1 . X X
2 . X X
3 . X X
4 . X X
5 . X X
6 . X X
X X X X
STEP
8 . X X
D A T A
Press Display
MODE
Twice
INSTALLATION
