- Installation & Servicing
SHORT LIST OF PARTS
The following are parts commonly required as replacements,
due to damage or expendability.
A full list of spares is held by Caradon Ideal Limited
distributors and merchants.
Their failure or absence will affect the safety and/or
performance of this appliance.
When ordering spare parts please quote:
1. Boiler model
2. Boiler serial no. (refer to the data plate on boiler)
3. Boiler P.I. No. (refer to the data plate on boiler)
4. Description
5. Quantity
6. Part no.
Key No. Description Total Qty. Part No.
Per Boiler
23 Air Pressure Switch (1 per Burner) 605 38-53 4 to 7 173 039
24 Fan (1 per Burner) 55667.00291 4 to 7 173 030
25 Gas Valve (1 per Burner) VK 4115 10552 4 to 7 173 031
17 Ignition Electrode (1 per Burner) 08210716 4 to 7 173 023
18 Detection Electrode (1 per Burner) 08210711 4 to 7 173 024
23 Auto Air Vent 1 173 029
32 Global Flow/Return Sensor T7335D1040 12K 2 173 038
32 Module Temperature Sensor (1 per Section) T7335D1040 12K 5 to 8 173 038
1 Module Temperature O/H Sensor (1 per Section) T7335D1040 12K 5 to 8 172 994
29 MBD Control Board 1401 912116.3 1 173 035
31 AM4 Control Board 1 173 037
30 AM5 Control Board 0 to 3 173 036
34 Gas Pressure Switch 1 173 040
37 Pressure Gauge 964 1 173 043
2 Display Screen 1 172 995
3 Push Button Panel 1 172 996
26 CVI Board (1 per Burner) S4865 D10041 4 to 7 173 032
Control Module Fuses (MBD) 2 173 640
27 Burners (1 per Burner) 4 to 7 173 033
28 Burner Gasket (1 per Burner) 4 to 7 173 034
6 Sight glass kit 4 to 7 172 999
5 Gas Valve Gasket Set 4 to 7 172 998
14 Fan Gasket 4 to 7 173 015
35 Reset Button 4 to 7 173 041
4 ON/OFF Switch 1 172 997
When replacing any part on this appliance use only spare parts that you can be assured conform to the safety and performance
specification that we require. Do not use reconditioned or copy parts that have not been clearly authorised by Ideal boilers.
To Next Page
