2
- Installation & Servicing
GENERAL
Note.
Natural gas consumption is calculated using a calorific value of
37.8MJ/m
3
(1038Btu/ft
3
) gross or 34 MJ/m
3
(910 Btu/ft
3
) nett at
15ºC and 1013.25 mbar.
a
. For l/s divide the gross heat input (kW) by the gross C.V. of
the gas (MJ/m
3
)
b. For ft/h
3
divide the gross heat input (Btu/h) by the gross C.V.
of the gas (Btu/ft
3
).
Propane gas consumption is calculated using a calorific value of
95.7 MJ/m
3
(2500 Btu/ft.
3
) gross or 88.0 MJ/m
3
(2300 Btu/ft.
3
) net
at 15ºC and 1013.25 mbar.
To obtain the fuel consumption in liquid form divide the above
figures by 270.
* The value is used in the UK Government's Standard Assessment
Procedure (SAP) for energy ratings of dwellings. The test data from
which it has been calculated have been certified by a notified body.
Table 1 Performance Data
Boiler W45 W45P W60 W60P W80 W80P
Boiler output Max kW 43.7 58.9 78.2
(non-condensing) Btu/h 149,000 200,950 266,800
Mean 70ºC Min kW 12.6 12.6 19.5
Btu/h 43,000 43,000 66,500
Boiler output Max kW 46.9 45.9 62.3 60.6 82.7 80.0
(condensing) Btu/h 160,000 156,000 212,550 206,750 282,150 272,950
Mean 40ºC Min kW 13.9 13.7 13.9 13.6 21.3 20.7
Btu/h 47,600 46,600 47,600 46,400 72,700 70,600
Boiler Input Nett kW 45.0 45.0 60.0 60.0 80.0 80.0
Max Rate Btu/h 153,550 153,550 204,700 204,700 272,950 272,950
Gross kW 49.9 48.9 66.5 65.1 88.7 86.9
Btu/h 170,250 166,850 227,000 222,300 302,700 296,350
Boiler Input Nett kW 13.0 13.0 13.0 13.0 20.0 20.0
Min Rate Btu/h 44,350 44,350 44,350 44,350 68,250 68,250
Gross kW 14.4 14.1 14.4 14.1 22.2 21.7
Btu/h 49,150 48,150 49,150 48,150 75,650 74,100
Gas Rate m
3
/h 4.76 1.84 6.35 2.45 8.46 3.27
ft
3
/h 168 65 224 86 299 115
Approx. flue gas volume m
3
/h 72 68 98 93 131 123
ft
3
/h 2,540 2,400 3,460 3,280 4,620 4,340
CO
2
@ Max Rate % 8.9 10.6 8.9 10.6 9.2 10.6
@ Min Rate % 8.7 10.3 8.7 10.3 9.0 10.3
NOx mg/kWh 45 42 55 65 60 63
ppm 26 24 31 37 34 36
Part load efficiency (Gross) % 96.4 97.2 96.4 97.5 96.4 97.0
*Seasonal efficiency (SEDBUK) Band A [90.0]% [91.3]% [90.4]% [92.0]% [90.2]% [91.6]%
Table 2 General Data
Boiler
W45 W45P W60 W60P W80 W80P
Gas supply 2H - G20 - 20mbar / 3P - G31 - 37mbar
Gas supply connection 22mm copper
Flow connection R 1
1
/4"
Return connection R 1
1
/4"
Max pressure (sealed system) bar (psi) 4.0 (58)
Maximum static head (m) 40.7
(ft) 133.8
Electricity supply 230V ~ 50Hz
Fuse rating External : 3A Internal : 1x2AF & 1x4AT
Power consumption (W) 51 84 120
IP rating IP20
Nominal flue dia - concentric (mm) 80/125 80/125 100/150
Nominal flue dia - twin pipe (mm) 80/80 80/80 100/100
Condensate drain (mm) 25
Water content (l) 8 8 10
(gal) 1.76 1.76 2.2
Weight (kg) 87 88 101
(lb) 191 194 222
HEALTH & SAFETY DOCUMENT NO. 635
The electricity at work regulations, 1989. The manufacturer's
notes must NOT be taken, in any way, as overriding statutory
obligations.
IMPORTANT. These appliances are CE certified for safety and
performance. It is, therefore, important that no external control
devices, e.g. flue dampers, economisers etc., are directly
connected to these appliances unless covered by these
Installation and Servicing Instructions or as otherwise
recommended by Caradon Ideal Limited in writing. If in doubt
please enquire.
Any direct connection of a control device not approved by
Caradon Ideal Limited could invalidate the certification and the
normal appliance warranty. It could also infringe the Gas Safety
Regulations and the above regulations.
