IDEC MICROSmart FC6A-C24R1CE User Manual

2: P RODUCT S PECIFICATIONS
2-68 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
Other Inputs and Ports
(1) Analog input
(2) Ethernet Port 1
(3) Ethernet Port 2
No. Signal Wire
1TPO+
2TPO-
3TPI+
4 ―
5 ―
6TPI-
7 ―
8 ―
Shell
*1
Shield
*1 Shell is connected to FE on the power supply terminals.
No. Signal Wire
1TPO+
2TPO-
3TPI+
4 ―
5 ―
6TPI-
7 ―
8 ―
Shell
*1
Shield
*1 Shell is connected to FE on the power supply terminals.
(1)
(2)
(3)
2
1
No. Signal Wire Cable Color
1AN(+) Red
2AN(-) Black
7
5
3
1
8
6
4
2
7
5
3
1
8
6
4
2
