FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722 2-141
2: P RODUCT S PECIFICATIONS
Terminal Arrangement and Wiring Examples
■ FC6A-SIF52, FC6A-SIF524
Screw fastened type: FC6A-SIF52 Push-in type: FC6A-SIF524
Applicable connector: FC6A-PMTC10PN02 Applicable connector: FC6A-PMSC10PN02
RS232C
/RS485
PW
S1
R1
S2
R2
FC6A-SIF52
SG2 B2 A2 NC SG2 DR2 RD2 SD2 ER2 RS2 SG1 B1 A1 NC SG1 DR1 RD1 SD1 ER1 RS1
RS232C
/RS485
PW
S1
R1
S2
R2
FC6A-SIF524
SG2 B2 A2 NC SG2 DR2 RD2 SD2 ER2 RS2 SG1 B1 A1 NC SG1 DR1 RD1 SD1 ER1 RS1
ER1(DTR)
RS1(RTS) Output
Output
Output
Input
Input
―
―
Input/output
Input/output
Terminal No. I/O
SD1(TxD)
RD1(RxD)
DR1(DSR)
SG1
NC
A1
B1
SG1
―
Request to send
Data terminal ready
Transmitted data
Received data
Data set ready
Signal ground
―
Data A
Data B
Signal Name
Signal ground
ER2(DTR)
RS2(RTS) Output
Output
Output
Input
Input
―
―
Input/output
Input/output
Terminal No. I/O
SD2(TxD)
RD2(RxD)
DR2(DSR)
SG2
NC
A2
B2
SG2
―
Request to send
Data terminal ready
Transmitted data
Received data
Data set ready
Signal ground
―
Data A
Data B
Signal Name
Signal ground
RS232C
Upper Side Port
RS485
RS232C
Lower Side Port
RS485
