1: G ENERAL I NFORMATION
1-4 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
Expansion interface module
Digital I/O cartridge
Analog I/O cartridge
Communication cartridge
FC6A -
EXM 2
Module configuration
1M: Remote master
1S: Remote slave
2: Expander
Module type
EXM: Expansion interface module
Terminal specification
1: Removable terminal block (Screw)
4: Removable terminal block (Push-in)
FC6A -
PN4
I/O points
4: 4 I/O points
Module type
PN : Digital input cartridge
PTS : Transistor source output cartridge
PTK : Transistor sink output cartridge
FC6A -
PK2A V
Input type
None: Voltage/current input
P: Resistance thermometer/thermocouple input
I/O points
2: 2 I/O points
Maximum resolution
A: 12 bits
C: 16 bits
Output type
V: Voltage output
W: Current output
None: No outputs
Module type
PJ: Analog input cartridge
PK : Analog output cartridge
FC6A -
PC1
Communication/terminal specifications
1: RS232C communication/terminal block
3: RS485 communication/terminal block
4: Bluetooth communication
Module type
PC : Communication cartridge
