FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722 1-5
1: G ENERAL I NFORMATION
Connector
*1 The type number for the MIL connector starts with "FC4A-" instead of "FC6A-".
Cable
FC6A -
PM 11PN02TCK
Wiring connection configuration
T: Screw fastened type
S: Push-in type
C: MIL connector
*1
Terminal specification
A: 5.08 mm pitch, side connection
B: 5.08 mm pitch, front connection
C: 3.81 mm pitch, front connection
D: 5.08 mm pitch, side connection
(dedicated for use with the CPU module
power supply terminal)
E: Front connection with screw flange
(dedicated for use with CAN communication)
None: MIL connector
*1
Quantity per pack
02: 2 items
Number of pins
03: 3 pins
05: 5 pins
08: 8 pins
09: 9 pins
10: 10 pins
11: 11 pins
12: 12 pins
13: 13 pins
17: 17 pins
20: 20 pins
Sale configuration
PN: 1 pack
Silk-screen printing
S: Silk-screen printing for source outputs
K: Silk-screen printing for sink outputs
A: Silk-screen printing for AC input
C: Silk-screen printing for 24-V DC input
D: Silk-screen printing for 12-V DC input
None: No silk-screen printing
Product classification
PM: Connector
FC9Z -
H0 A2050
Input type
A: Shielded straight cable
B: Non-shielded straight cable
Number of pins
20: 20 pins
Cable length
050: 0.5 m
100: 1 m
200: 2 m
300: 3 m
Cable classification
H: Flat cable
