FC6A S
ERIES
MICROS
MART
U
SER
’
S
M
ANUAL
FC9Y-B1722 2-161
2: P
RODUCT
S
PECIFICATIONS
(8) Ground Terminal
The functional ground terminal.
(9) Dummy Cartridge
A removable dummy cartridge that protects the cartridge slot. Remove the dummy cartridge when connecting a cartridge.
(10) HMI-Ethernet Port
This port allows Ethernet communication with connected devices that are equipped with an Ethernet interface.
Function Specifications
■ HMI-Ethernet Port Specifications
■ Ethernet Communication Specifications
■ LCD Specifications
Type No. FC6A-PH1
Rated Power Voltage (Supplied from
Module)
5V DC
24V DC
Connector
HMI-Ethernet Port RJ45
Insertion/Removal
Durability
100 times minimum
Module 5V DC 300 mA
Internal Current
Draw
24V DC 15 mA
Ground D-type ground (Type 3 ground)
Ground Wire UL1007 AWG18
Weight 170 g
Points 1
Communication Type IEEE 802.3 compliant
Communication Speed 10BASE-T, 100BASE-TX
Communication Functions Maintenance communication
Connector RJ45 (Auto MDI/MDI-X compatible)
Cable CAT 5 or higher, STP
Maximum Cable Length 100 m
Isolation between Internal Circuit Pulse transformer isolated
Number of Connections 8 maximum
Communication Mode Maintenance Communication
Web Server Function Yes
Web Data Storage FROM
Web Data Capacity 5 Mbyte (Total size of the system web page and user web page)
Send E-mail Function Yes
Type STN monochrome LCD
Resolution 64 x 192 pixels
Number of Characters
24 digits x 8 lines (8 x 8 pixel font)
12 digits x 8 lines (16 x 8 pixel font)
12 digits x 4 lines (16 x 16 pixel font)
Display Content System menus, messages, operation status monitor
Contrast Adjustment Not possible
Backlight Yes (can be turned on and off)
To Next Page
