2: P RODUCT S PECIFICATIONS
Ethernet Port 1
SD Memory Card Slot
Cartridge Slots
When the HMI module is connected, the analog I/O cartridge or the digital I/O cartridge can be expanded.
*1 All devices that are connectable to the cartridge slots cannot be used in expanded ambient operating temperatures (-25 to -10°C and 55 to
65°C). Do not connect these devices when the product is used in expanded ambient operating temperatures.
Communication Connector
*1 All devices that are connectable to the communication connector cannot be used in expanded ambient operating temperatures (-25 to -10°C
and 55 to 65°C). Do not connect these devices when the product is used in expanded ambient operating temperatures.
Points
1
(When the HMI module is connected, this can be expanded by 1 point with the Ethernet port
that has the web server function.)
Communication Type IEEE 802.3 compliant
Communication Speed 10BASE-T, 100BASE-TX
Number of Connections 8
Communication Functions Maintenance communication, user communication, Modbus TCP server/client
Connector RJ45 (Auto MDI/MDI-X compatible)
Cable CAT 5 or higher, STP
Maximum Cable Length 100 m
Isolation between Internal Circuit Pulse transformer isolated
Points 1
Supported SD Card SD memory cards (max 2 GB), SDHC memory cards (max 32 GB)
File System FAT16, FAT32
Function Downloading/uploading user programs
Insertion/Removal Durability 2,000 times
Type No.
FC6A-C16R1AE
FC6A-C16R4AE
FC6A-C16R1CE
FC6A-C16R4CE
FC6A-C16K1CE
FC6A-C16K4CE
FC6A-C16P1CE
FC6A-C16P4CE
FC6A-C16R1DE
FC6A-C16R4DE
FC6A-C16K1DE
FC6A-C16K4DE
FC6A-C16P1DE
FC6A-C16P4DE
FC6A-C24R1AE
FC6A-C24R4AE
FC6A-C24R1CE
FC6A-C24R4CE
FC6A-C24K1CE
FC6A-C24K4CE
FC6A-C24P1CE
FC6A-C24P4CE
FC6A-C40R1AE
FC6A-C40R4AE
FC6A-C40R1CE
FC6A-C40R4CE
FC6A-C40K1CE
FC6A-C40K4CE
FC6A-C40P1CE
FC6A-C40P4CE
FC6A-C40R1DE
FC6A-C40R4DE
FC6A-C40K1DE
FC6A-C40K4DE
FC6A-C40P1DE
FC6A-C40P4DE
FC6A-C40R1AEJ
FC6A-C40R4AEJ
FC6A-C40R1CEJ
FC6A-C40R4CEJ
FC6A-C40K1CEJ
FC6A-C40K4CEJ
FC6A-C40P1CEJ
FC6A-C40P4CEJ
FC6A-C40R1DEJ
FC6A-C40R4DEJ
FC6A-C40K1DEJ
FC6A-C40K4DEJ
FC6A-C40P1DEJ
FC6A-C40P4DEJ
Cartridge Connections
*1
Slots 1122
HMI Module Connection
*1
Slots 1

IDEC MICROSmart FC6A-C24R1CE Specifications

General

Brand	IDEC
Model	MICROSmart FC6A-C24R1CE
Category	Computer Hardware
Language	English
