13: T ROUBLESHOOTING
13-16 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
Troubleshooting Diagram 6
Note: To turn off M8000, enter 0 in the Current Value box in the Custom Monitor dialog box.
For details on special internal relay M8000, see "M8000: Start Control" on page 6-9.
Does the monitored input
turn on and off?
NO
YES
NO
YES
YES
Call IDEC for assistance.
Monitor the designated stop or reset
input using WindLDR on a computer.
NO
Is the designated stop or
reset input on?
Is M8000 off?
Turn on the designated input.
The input circuit in the FC6A Series
MICROSmart is damaged.
Replace the FC6A Series MICROSmart.
Is stop or
reset input designated in
the WindLDR Function Area
Settings?
Monitor the start control special internal
relay M8000 using WindLDR on a
computer.
YES
Turn off the start control special internal
relay M8000 using WindLDR on a
computer.
NO
Cannot stop or reset operation.
Note: To monitor M8000, from the WindLDR menu bar, select
Online > Monitor > Monitor, then Online > Custom > New
Custom Monitor. Enter M8000 in the Device box in the Custom
Monitor dialog box.
