(1) Battery Holder
This holder is for installing the backup battery.
(2) SD Memory Card Slot
This slot is used to insert the SD memory card.
(3) Power LED [PWR]
This LED turns on when the power is supplied to the CPU module.
(4) Run LED [RUN]
This LED turns on while the CPU module is running the user program.
This LED flashes when using certain functions while the user program is running.
(5) Error LED [ERR]
This LED turns on when an error occurs in the CPU module.
(6) SD Memory Card Status LED [SD]
This LED turns on or flashes when the SD memory card is being read or written.
(7) Battery Status LED [BAT]
This LED turns on or flashes when the backup battery level is low.
(8) Status LED [STAT]
This LED can be turned on or off in the user program.
(9) Input LEDs [IN]
These LEDs turn on when the corresponding input is on.
(10) Output LEDs [OUT]
These LEDs turn on when the corresponding output is on.
(11) Expansion Connector
This connector is used to connect an expansion module.
(12) Output Terminals
These terminals connect output devices such as electromagnetic switches and solenoid valves. The CPU module is available
in the relay output type (240V AC: 2 A, 30V DC: 2 A), the transistor sink output type (0.5 A), and the transistor protection
source output type (0.5 A).
LED Status
ON While the CPU module is running the user program
Slow flashing (1 s cycle) When executing the forced I/O function while the user program is running
Quick flashing (100 ms cycle)
While the CPU module is in USB boot
When executing the forced I/O function while the user program is stopped
LED Status
OFF
When the SD memory card is not inserted
When an unsupported or unformatted SD memory card was inserted
Unmount SD memory card (M8072) is on, so the SD memory card has been unmounted
When the FC6A Series MICROSmart power is off
ON The standby state where the SD memory card can be written or read
Slow flashing (1 s cycle)
When the FC6A Series MICROSmart is recognizing the SD memory card
Unmount SD memory card (M8072) is turned on and the FC6A Series MICROSmart is
unmounting the SD memory card
Quick flashing (100 ms cycle) Reading or writing the SD memory card
LED Condition Battery Status
OFF Battery voltage (D8056) > 2,300 Normal Sufficient battery level.
Flashing (1 s cycle) 2,300 battery voltage (D8056) > 2,000 Warning Low battery level. Replace the battery.
ON 2,000 battery voltage (D8056) Dead battery The battery is almost dead. Or no battery.
