2: P RODUCT S PECIFICATIONS
2-52 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
(31) Ethernet Port 2 Cover
A removable cover that protects Ethernet Port 2. When using the Ethernet port, remove the Ethernet Port 2 cover.
(32) Ethernet Port 1 Cover
A removable cover that protects Ethernet Port 1. When using the Ethernet port, remove the Ethernet Port 1 cover.
(33) Communication Connector Protection Sticker
This sticker protects the communication connector. Remove the communication connector protection sticker when
connecting the HMI module or cartridge base module.
