FC6A S
ERIES
MICROS
MART
U
SER
’
S
M
ANUAL
FC9Y-B1722 2-53
2: P
RODUCT
S
PECIFICATIONS
Power Supply Specifications
■ 24V DC Power Type
Type No.
FC6A-D16R1CEE, FC6A-D16R4CEE, FC6A-D16K1CEE, FC6A-D16K4CEE, FC6A-D16P1CEE,
FC6A-D16P4CEE, FC6A-D32K3CEE, FC6A-D32K4CEE, FC6A-D32P3CEE, FC6A-D32P4CEE
Rated Power Voltage 24V DC
Voltage Fluctuation Range 20.4 to 28.8V DC (including ripple)
Maximum Power Consumption Standalone When Maximum Load is Connected
FC6A-D16R1CEE/
FC6A-D16R4CEE
2.88 W (24V DC) 18.24 W (24V DC)
FC6A-D16K1CEE/
FC6A-D16K4CEE
2.88 W (24V DC) 18.24 W (24V DC)
FC6A-D16P1CEE/
FC6A-D16P4CEE
2.88 W (24V DC) 18.24 W (24V DC)
FC6A-D32K3CEE/
FC6A-D32K4CEE
3.36 W (24V DC) 18.72 W (24V DC)
FC6A-D32P3CEE/
FC6A-D32P4CEE
3.36 W (24V DC) 18.72 W (24V DC)
Allowable Momentary Power
Interruption
10 ms or longer (when rated power supply voltage)
Withstand Voltage
Between power and FE terminals: 500V AC, 1 minute
Between input and FE terminals: 500V AC, 1 minute
Between transistor output and FE terminals: 500V AC, 1 minute
Between relay output and FE terminals: 2,300V AC, 1 minute
Between power and input terminals: 500V AC, 1 minute
Between power and transistor output terminals: 500V AC, 1 minute
Between power and relay output terminals: 2,300V AC, 1 minute
Between input and transistor output terminals: 500V AC, 1 minute
Between input and relay output terminals: 2,300V AC, 1 minute
Insulation Resistance
Between power and FE terminals: 100 MΩ or higher (500V DC insulation resistance tester)
Between input and FE terminals: 100 MΩ or higher (500V DC insulation resistance tester)
Between transistor output and FE terminals: 100 MΩ or higher (500V DC insulation resistance tester)
Between relay output and FE terminals: 100 MΩ or higher (500V DC insulation resistance tester)
Between power and input terminals: 100 MΩ or higher (500V DC insulation resistance tester)
Between power and transistor output terminals: 100 MΩ or higher (500V DC insulation resistance
tester)
Between power and relay output terminals: 100 MΩ or higher (500V DC insulation resistance tester)
Between input and transistor output terminals: 100 MΩ or higher (500V DC insulation resistance
tester)
Between input and relay output terminals: 100 MΩ or higher (500V DC insulation resistance tester)
Inrush Current 35 A maximum
Isolation Between power terminal and internal circuit: Transformer isolated
Ground D-type ground (Class 3 ground)
Grounding Wire See "Recommended Ferrule List" on page 3-46.
Power Supply Wire
See "Recommended Ferrule List" on page 3-46.
Effect of Improper Power Supply
Connection
Reverse polarity: Normal operation
Improper voltage or frequency: Permanent damage may be caused
Improper lead connection: Permanent damage may be caused
