Power supply
14
External Power Supply: 12-24 V (regulated and filtered) 3A min @12V, IEC60950-1 or IEC 62368-1 standard
compliant. If sharing power between devices, each unit must receive 3A (e.g. two units would require a 12
VDC, 6A supply).
Step two : wiring
A battery backup or uninterrupted power supply (UPS) with built-in surge protection is recommended.
WARNING: Under powering may cause memory and data corruption; over powering may cause hardware damage.
Both of these situations will void the warranty
(mm
2
)
Maximum distance (meters) vs
power source rating
12 V +/-
10%
3,6 A
12 V +/-
5%
3,5 A
24 V +/-
10%
2 A
24 V +/-
10%
3 A
16 1.31
6 m 12 m 68 m 121 m
18 0.82 4 m 8 m 43 m 76 m
20 0.52
2 m 5 m 27 m 48 m
22 0.32 1 m 3 m 16 m 30 m
IDEMIA recommends using a 24V 3A power supply and
AWG16 gauge cable. The voltage measured on the product
block connector of the terminal must be equal to 12V-24V (-
15% / +10%).
The product requires 36 W at all voltage conditions.
The voltage drop due to the cable shall be taken into account.
The table at the right, shows the maximum distance between
power supply and 1 unique device, depending on cable gauge
and power supply rating.
