24 25
STEP 4
Remove the wires from the Common terminal on both of the
existing switches and cap with the provided wire nuts. Note: The
common terminals usually have a screw that is either black or copper
in color.
LINE LOAD
NEUTRAL NEUTRAL
TRAVELER TRAVELER
COMMON
COMMON
GROUND
GROUND
