26 27
STEP 5
Turn the power back on at the breaker. Using your voltage detector,
identify which of the 2 common wires you removed is energized.
This is the “line” wire. Mark this wire as the Secondary (S) Switch
Position. You will need to refer to this during the Pairing and Setup
Process.
The common wire that is not energized is the “load” wire. Mark as
the Primary (P) Switch Position. You will need to refer to this during
the Pairing and Setup Process.
