STEP 7
Install the iDevices
®
Wall Switches according to the diagram. Ensure
the wire nuts are securely fastened.
Ensure you install a wire nut on the red lead on the secondary switch
as well as on both ends of the traveler wire (typically red wire)
LINESECONDARY SWITCH
LOAD PRIMARY SWITCH
NEUTRAL NEUTRAL
TRAVELER TRAVELER
COMMON
LINE
GROUND GROUND
LOAD
S
P
