15
NEUTRAL
(White)
NEUTRAL
(Usually White)
LOAD
(Usually Black)
LOAD
(Red)
GROUND
(Bare Copper)
GROUND
(Usually Bare Copper
or Green)
LINE
(Usually Black, Red or Blue)
LINE
(Black)
