42
REFERENCE INFORMATION
LED COLOR CODES
LED State Description
Blue Flash
Wall Switch is waiting for the handset to congure the accessory’s
Wi-Fi
®
. The LED ashes blue.
Solid Blue
Wall Switch is waiting for the mobile device to initiate and complete pair set
up. The LED is solid blue. Note: Pairing mode expires after 30 minutes; to
reinitiate pairing mode, press the Pairing Button
6
down for 3 seconds and
the LED will turn solid blue again.
Slow Blue Flash
Pairing mode has expired and Wall Switch is waiting for the user to press the
Pairing Button
6
down for about 3 seconds to re-enter pairing mode. The
LED slowly ashes blue.
Green Flash
When Wall Switch joins a Wi-Fi
®
network, (e.g., the link is up) the LED ashes
green for 1 second.
