23
TRAVELER
(Usually Black or Red)
TRAVELER
(Usually Black or Red)
NEUTRAL
(Usually White)
NEUTRAL
(Usually White)
LINE
(Usually Black)
LOAD
(Usually Black)
GROUND
(Usually Bare Copper or Green)
GROUND
(Usually Bare Copper or Green)
