Idex HALE MIV 2.0 User Manual

46
Table 11. MIV-E INSTALLATION KIT
Part Number
Qty
Name of Part
513-0273-52-0
1
MIV-E PLACARD & HARNESS ASSEMBLY
102525
8
NUT, 8-32 HEX, SS
064-7330-00-0
2
MIV EXTENSION GROOVE PIN
113404-007
1
ADAPTER, MIV-E HANDLE
113404-004
ADAPTER, MIV-E HANDLE
101-1482-02-0
1
MIV-E MANUAL OVERRIDE PLACARD
012-1420-00-0
1
MIV MANUAL OVERRIDE KNOB
102529
8
SCREW, PAN PH 8-32 X 0.75 SS
018-1212-63-0
1
SCREW-1/4-20 X 1-1/4 PLTD
513-00144-000
1
HARN, MIV CONTROL (NOT SHOWN)
513-0270-04-0
1
HARN, MIV POWER CABLE WIRING (NOT SHOWN)
Table 12. MIV-M INSTALLATION KIT
Part Number
Qty
Name of Part
512-0070-00-0
1
ASSY WHEEL MANUAL ADJUSTING
018-1214-45-0
1
SCREW,RND HEAD,1/4-20 X 1.5
113404-007
1
ADAPTOR, MIV-E HANDLE
113404-004
ADAPTOR, MIV-E HANDLE
064-7330-00-0
1
MIV EXTENSION GROOVE PIN
513-0273-53-0
1
MIV-M PLACARD & HARNESS ASSEMBLY
102525
4
NUT, 8-32 HEX, SS
102529
4
SCREW, PAN PH 8-32 X 0.75 SS
110-1205-11-0
1
NUT, NYLOCK 1/4-20 SS
513-00144-000
1
HARN, MIV CONTROL (NOT SHOWN)
513-0270-04-0
1
HARN, MIV POWER CABLE WIRING (NOT SHOWN)
Table 13. MIV-E GEARBOX REPLACEMENT ASSEMBLY – 538-00075-000
Part Number
Qty
Name of Part
538-00074-000
1
MIV-E GEARBOX ASSEMBLY
113404-004
1
ADAPTER MIV GEARBOX HANDLE
113404-007
1
ADAPTER MIV GEARBOX HANDLE
064-7330-00-0
2
MIV EXTENSION GROOVE PIN
Table 14. MIV-E GEARBOX REPLACEMENT ASSEMBLY – 538-00075-000
Part Number
Qty
Name of Part
538-00072-000
1
MIV-M ACTUATOR ASSY STRONGWELL
064-7330-00-0
2
MIV EXTENSION GROOVE PIN
113404-004
1
ADAPTER MIV GEARBOX HANDLE
113404-007
1
ADAPTER MIV GEARBOX HANDLE
