5 HOW TO ASSEMBLE THE SYSTEM AND SAFETY GUIDELINES Mod: MDM/011/M2 Rev 8
IDS GeoRadar Srl MNG/2022/007 Rev. 1.0 25/ 36
9. Connect two-wheel cables and turn ¼ to fasten (Fig. 23)
10. Connect the LAN cable from the antenna to the tablet port (Fig. 23)
Fig. 23 - Connection overview
11. Turn the system on (Fig. 24)
12. Launch uMap software on the data logger
Fig. 24 - Stream DP operative mode
