IDS GeoRadar s.r.l. MN/2017/011 Rev 1.0 12/ 38
C-Thrue main body
The C-Thrue main body dimension are 285 mm x 200 mm x 160 mm
or 11,2 in x 8,6 in x 6,3 in (length x width x height) and its weight is
2,4 Kg (5 lB), including battery.
• Environment feature: IP 65
• Operating temperature: -20/+50 °C
The main body of the system consists of the following parts (Fig. 3):
• Multi-Touchscreen for the embedded PC.
• Integrated Control unit
• 4 wheels for distance measurement and encoder-to-DAD
input
• Handle
• Battery compartment
• USB port for radar data transfer and software updating,
Fig. 4.
• Power button to switch on/off the system, Fig. 4.
• Remote control connector interfaces, Fig. 4.
Fig. 3 – Image of the C-Thrue and its main components
Fig. 4 – Detail of the USB port, Power button and remote control connector interfaces
