IDS Optex Xwave

10. HX-80NRAM
The 862-01-HX-80NRAM is an intelligent long
range outdoor detector with two PIR lenses and
Anti-Masking protection.
10.1. Hardware
Dip Switch
1 – Walk Test Mode
2 – Battery Saving Timer
3 – Immunity
4 – Trouble Output Type
5 – Low Battery Output
6 – LED
Top PIR Lens
Bottom PIR Lens
PIR Sensitivity Selector
H – High
M – Medium
L – Low
Tamper Switch
PIR LED Indicator
Anti- Masking Sensitivity
Selector
H – High
M – Medium
L – Low
Top Masking Flap
Bottom Masking Flap
