IDS Optex Xwave

Supervision Jumper
J1 On – 90 mins
J1 Off – 12 hrs
IDS Wireless
Transmitter
Battery Holder
Power Connector
Connect the battery
holder lead here.
Detector Inputs
Tamper & PIR inputs
come from the
detector.
Battery Holder
Holds 3 x CR 123A
batteries
IDS Wireless
Transmitter
