IEI Technology NOVA-945GSE User Manual

4
Connector /Jumper List
LABEL FUNCTION
ATXCTL1 Power on mode setup
BT1 Battery Connector
CN1
CN2
SATA1, SATA2 Power Connectors
COM1
COM2
COM4
Internal Serial Port Connectors (RS-232)
COM3 Internal Serial Port Connectors (RS-232/422/485)
DIMM1 DDR2 SO-DIMM Slot
DIO1 Digital I/O Connector
F_PANEL1
PWR、RST Buttons、Indicators
IDE1 44PIN IDE Connector
INVERTER1
INV2
LVDS Panel Voltage Supply Connector
IR1 Infrared Interface Connector
J_CF1 CF Card Master/Slave setting jumper
J_CMOS1 CMOS state setting jumper
J_LCD_TYPE1 LVDS Panel Resolution Selection jumper
J_VLVDS1
J_VLVDS2
LCD Voltage Selector jumper
J1 System Fan Connector
J2 Main Power Input Connector
J3 LPT Connector
J4 PC/104+ Connector (PCI-BUS)
J5 3Pin ATX Power Connector
J6 PC/104 Connector (ISA-BUS)
J7 CRT CONNECTOR
J8 Audio Connector
J9 CF Card Slot
JP1 Configure COM3 Mode jumper
JP2 COM3 RS-422/485 connector
JP4 LVDS Panel Resolution Selection jumper
KB1 PS/2 MOUSE & KEYBOARD Connector
LAN1
LAN2
RJ-45 LAN Connectors
LVDS1 LVDS Panel Connector (18-bit)
LVDS2 LVDS Panel Connector (24-bit)
