IEI Technology NOVA-945GSE User Manual

6
J3: LPT Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 STROBE# 14 ALF#
2 PD0 15 ERROR#
3 PD1 16 PAR IN#
4 PD2 17 SLINTIN#
5 PD3 18 GND
6 PD4 19 GND
7 PD5 20 GND
8 PD6 21 GND
9 PD7 22 GND
10 ACK# 23 GND
11 BUSY 24 GND
12 PE 25 GND
13 SLCT 26 N/C
USB1, USB2, USB3 : Internal USB
Connectors
PIN
DESCRIPTION
PIN
DESCRIPTION
1 VCC(+5V) 2 GND
3 DATA- 4 DATA+
5 DATA+ 6 DATA-
7 GND 8 VCC(+5V)
