IEI Technology PCISA-6770-RS User Manual

4
Label Function
IDE1 Ultra ATA100 Primary (40 Pin)
IDE2 Secondary IDE connectors (44 PIN )
FDD1 Floppy connector
LPT1 Parallel port connector
DIO1 Digital I/O
COM1 Serial port connector(10 Pin)
COM2 RS-232/422/485 connector(14 PIN)
J1 Compact Flash Storage Card Type II connector
IR1 IRDA infrared interface port
USB1 USB port connector
USB2 USB dual port connector
USB3 USB dual port connector
J4 LAN1 RJ45 (10/100) connectors
J5 LAN2 RJ45(10/100/1000(optional)) connectors
KBM1 6-pin Mini-Din Keyboard & Mouse connector
KB1 External 5-pin Header Keyboard Connector
FAN1 FAN connector
CN3 External switches and indicators
CD-IN Audio CD IN connector
CN4 Backplane to CPU board ATX power control Connector
DVI DVI DISPLAY( Optional)
LVDS1 LVDS1 CONNECTOR
CN1 Backlight Inverter Connector
COM1 : 10-pin header onboard
COM2 : 14-pin header onboard
PIN DESCRIPTION PIN DESCRIPTION
1
DATA CARRIER
DETECT (DCD)
2
DATA SET READY
(DSR)
3
RECEIVE DATA
(RXD)
4
REQUEST TOSEND
(RTS)
5
TRANSMIT DATA
(TXD)
6
CLEAR TO SEND
(CTS)
7
DATA TERMINAL
READY (DTR)
8
RING INDICATOR
(RI)
9 GROUND
10 NC
(11)
RS-422 TX+
RS-485 Data+
(12)
RS-422 TX-
RS-485 Data-
(13) RS-422 RX+
(14)
RS-422 RX-
