IEI Technology PCISA-6770-RS User Manual

3
Ordering Information
Standard
PCISA-6770E2-RS-R20
PCISA Intel Pentium-M/Celeron-M CPU Card with LCD/CRT VGA,Dual
LAN,USB2.0 and Audio
PCISA-6770E2-RS-800Z-R20
PCISA Intel Celeron-M 800MHz Zero Cache CPU Card with LCD/CRT
VGA,Dual LAN,USB2.0 and Audio
Optional:
1. FDD cable P/N:32200-000058-RS
2. RS232/LPT cable P/N: 19800-000027-RS
Jumpers setting and Connectors
LABEL FUNCTION
JP1 CMOS state setting
JP2 CompactFlash Master(1-2)/Slave(2-3) setting
JP3 LVDS LCD power source 3.3V(1-2)/5v(2-3) setting
JP1 : Clear CMOS Setup
JP1 DESCRIPTION
1-2 Normal Operation
2-3 Clear CMOS Setup
JP3 : 3.3V/5V Mode Setting
JP3 DESCRIPTION
1-2 3.3V
2-3 5V
JP2 : Master/Salve Mode
Setting
JP2 DESCRIPTION
1-2 Master
2-3 Slave

IEI Technology PCISA-6770-RS Specifications

General

Brand	IEI Technology
Model	PCISA-6770-RS
Category	Motherboard
Language	English
