Parameter
Values
Description
Reader B Hold
Check why the Reader B command is being maintained on the
control board connector block
Position Fail
The type of sensor selected is Analogue Sensor (QUICK START
► menu Positioning); nevertheless, the obstacle still has to be
activated (► Activate Motor? ► OK).
Counter CR
 The reader counter (see the OPTIONS menu 
Counter CR) is greater than zero.
 Or the timing for no passage is other than zero (see
the TIMING menu  No Passage).
Open Status
Cases when the obstacle is prevented from opening during a
request to open.
OK
Normal opening.
Lock CL Hold
Check why the Lock CL command is being maintained on the
control board connector block.
Lock Close LCD
The Test Mode parameter of the TEST menu is not set to
Deactivated.
Delay Befor OP
Wait for the time programmed under the Delay Bef. OP under
the TIMING menu to elapse.
Stop Cmd Hold
 Check why the close order is being maintained on the
control board connector block.
 Check whether the Stop CMD parameter is
programmed correctly (Options menu).
Arm ELV Locked
 Check whether the detector of the unlocking of the
electrically locking (ELV) tip is functioning properly.
 Check whether the Arm parameter in the OPTIONS
menu is programmed correctly.
Arm ELV Detect
Check whether the detector sensing the presence of the
arm is functioning properly on the control board connector
block.
Position Fail
The type of sensor selected is Analog. Sensor (QUICK START
menu ► Positioning); nevertheless, the obstacle still has to be
activated (► Activate Motor? ► OK).
Counter 1
0 to 99,000,000
(0 by default)
Total number of manoeuvres executed by the obstacle since it
was first put into service.
Counter 2
0 to 99,000,000
(0 by default)
Representation of counter 1, with the possibility of resetting it to
zero.
Reset counter 2
Counter 2 reset to zero.
OFF (by default)
No resetting.
ON
Request to reset to zero.
Done
Message is displayed for 1 second when the counter has been
reset to zero.
