7.1. Control blocks assignment
Connector block number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Connectors
A
GND
GND
GND
GND
24V
24V
24V
GND
GND
GND
REL3 -
Output relay 3
REL3 +
Output relay 3
GND
GND
GND
GND
B
AO1
FI setting
DO11 PWM
Output 11
DO8
Descending motor
24V
DI13
Closing LS
DI11
Lock Close CMD
DI9
Close command
24V
24 V
24V
REL2 -
Output relay 2
REL2 +
Output relay 2
24V
24V
24V
24V
C
AI1
Analog. Sensor
DO10sPWM
Output 10
DO7
Rising motor
DI14
crank limit switch
DI12
Opening LS
DI10
Lock Open CMD
DI8
Open command
DI7
Stop command
DI6
Reader A command
DI5
Swing off sens./Lock
REL1 -
Output relay 1
REL1 +
Output relay 1
DI4
Cell 4
DI3
Cell 3
DI2
Cell 2
DI1
Cell 1
A In/Out
B connector blocks.
C
X13 Inductive loops
X14 connectors.
X9 Connectors for
X11 inductive loops presence
detectors.
Y Inductive loops presence
detector.
A
B
C
1 2 3 4 5 6 ........................... 16
X14
X11
DP1
DP2
DP3
DP4
Y
DP1
DP2
DP3
DP4
X13
X9
