IES EC 12 - Dimmer Overview

8. DIMMER OVERVIEW
A Dimmer channel 1-4
B Dimmer channel 5-8
C Dimmer channel 9-12
D ceramic fuse 6,3 A
E Blower
F Glass fuse 400mA
G Output 7-12
H Output 1-6
I Power input 3 x 230VAC
IES EC24 & EC12 dimmer pack Operators’ Manual v. 1.0 20-10-2003
7
