9. Specifications
product ref.: EC 12 EC 24
Order code: 9602 9804
star/delta - -
Channels: 12 12
electrical specification:
Load per Ch.: 1250W 2.3kW
Supply Voltage: ----- 180V to 260V AC -----
Supply frequency: ----- 50Hz - 60Hz -----
Supply phase: three three
Supply Amps: 3 x 23A 3 x 40A
Minimum load: ----- 10W -----
Load phase angle: ----- 0.8 to unity -----
Power device triac triac
Non-dim function ----- per channel -----
Max. Ambient °C: ----- 50°C -----
circuit protection:
FUSE: ----- 6,3A per channel ----
weights & dimensions:
Size: ---- 483mm x 93mm x 280mm ----
Weight: ---- 6.0kg ----
connectors:
Supply connection: ---- 5 x 4mm
2
cable ----
output sockets: 12 6 x 2
Output type: HAN E 16F Harting
product ref.: EC12 EC24
Control connectors (in and out) ----- XLR-5 -----
DMX data ----- pins 2+3 -----
Data ----- pins 4+5 -----
control data:
Control signal: DMX-512 4-wire (DMX and DATA
bi-directional data)
Max. level preset: 30.0% - 100% (full)
Min. level preset: 0.0% - 29.9%
Response time: 0.00 secs - 9.9 secs (up and dn)
Dimmer curves: 8 8
DMX backup: programmable for hold or backup
memory
standards:
Low voltage directive: complies with 76/23/EEC
EMC directive: complies with 89/336/EEC
IES EC24 & EC12 dimmer pack Operators’ Manual v. 1.0 20-10-2003
8
