iFan IF9010 - Page 3

10.
EVA Filter
11.
Continuous Drainage Hole
12.
Air Vent
13.
Wrapping Post
14.
Con Filter
15.
Drainage Hole
⑩&&EVA Filter
⑪&&Continuous Drainage Hole
⑫&&Air Vent
⑬&&Wrapping Post
⑭&&Con Filter
⑮&&Drainage Hole
Exhaust Pipe Assembly
Window Sealing Plate Assembly
