IFM AL1340 - Modbus TCP Register Configuration

IO-Link Master with Modbus TCP Interface DataLine 4 Ports IP 65 / IP 66 / IP 67
65
>
9.3.2 Set IO-Link master
54624
Register area for the access to the configuration of the IO-Link master: →Configuration Area
(→ S. 88)
The area contains the following data:
 Access rights to the IO-Link master
 Data length of the IO-Link input and output data of all IO-Link ports
 Alignment of the bytes in a data word
► Observe the general rules for access to the Modbus registers (→Rules for accessing the
Modbus registers (→ S. 73))!
► When writing several registers at conce, ensure that the transferred parameter data has
the correct length!
Register
Content
Access
8998
Access Rights; Process Data Length
r/w
8999
Byte Swap
r/w
r/w ... read and write
