IFYIL GALATA - Page 48

1- Radiator water outlet
2- Radiator water inlet
3- Anti-condensation valve
4- Safety valve evacuation
5- Power supply inlet
7- Chimney outlet
8- Exchanger hot water outlet
9- Exchanger cold water inlet
10- Boiler
11- Plumbing water unloading
valve
12- Plumbing water loading
valve
13- Mains water inlet line
14- Sanitary hot water line
BOSPHORUS PLUMBING SCHEMA
