Igema TG32 - Technical Data

12
4. Technical Data
4.1 Device dimensions
One sight glass opening
Sight glass openings offset to each other
*L=Abhängig vom Prozessanschluss
Ü=min. 26mm
*L=Abhängig vom Prozessanschluss
The dimensions H/J, E and A are stated in your order and can be viewed.
All other dimensions can be found in the following tables.
Single show length
Size
Visible length
(Dimension E)
Process connection length (Dimension A)
Min.
Max.
5
200mm
7
7
8
⁄
"
280mm
11 "
400mm
15
3
4
⁄ "
6
230mm
9 "
310mm
12
1
5
⁄ "
430mm
17 "
7
260mm
10
1
4
⁄ "
340mm
13
2
5
⁄ "
460mm
18
1
9
⁄
"
8
300mm
11
4
5
⁄ "
380mm
15 "
500mm
19
2
3
⁄
"
9
320mm
12
3
5
⁄ "
400mm
15
3
4
⁄ "
520mm
20
1
2
⁄ "
10
350mm
13
7
9
⁄
"
430mm
17 "
550mm
21
2
3
⁄
"
11
380mm
15 "
460mm
18
1
9
⁄
"
580mm
22
5
6
⁄
"
