9
Changing the Shackle
Unlock the Padlock E and pull the shackle to
open position. Turn Torx cap clockwise 120°
with the Torx Screwdriver & push battery
cover out.
Remove the battery cover, locate sticker to
remove and use a sharp object to remove
the retaining pin. The shackle is now
removable.
Replace with the long shackle and place
the retaining pin and sticker back in the
original position. Ensure that the long
shackle remains in the opened position.
Secure the battery cover by turning the torx
cap counter-clockwise 120° with the Torx
Screwdriver while the Padlock E is unlocked.
Push the shackle in and you’re done!
Sticker
Retaining
Pin
2
3 4
Please ensure
that the marking
on the torx cap
is aligned to the
marking on the
padlock.
