Ignition LED STUDIO PAR PLATINUM - DMX Modes

LED Studio Par Platinum 20x3W PWM
7 / 12
Determines the maximum intensity of the colour green 0 % - 100%. This setting overwrites every
other setting like the max output in manual or DMX mode and the built in programs.
Determines the maximum intensity of the colour blue 0 % - 100%. This setting overwrites every
other setting like the max output in manual or DMX mode and the built in programs.
4. Reset / Hold
If you push and hold +/- for more than 3 sek., the SETUPDIM will do a reset.
5. DMX Mode
DMX Mode: (Display blink, if there is no DMX signal)
Connect the signal out of you controller with the XLR in plug on the fixture.
On the XLR out you can connect other DMX controllable fixtures.
