Ignition LED STUDIO PAR PLATINUM - DMX Mode 5; DMX Mode 6 (Compatibility)

LED Studio Par Platinum 20x3W PWM
9 / 12
DMX MODE 5
Chanel Value Function
1 0-255 RED: 0 = OFF, 1-255 = DIMMER 1-100% OUTPUT
2 0-255 GREEN: 0 = OFF, 1-255 = DIMMER 1-100% OUTPUT
3 0-255 BLUE: 0 = OFF, 1-255 = DIMMER 1-100% OUTPUT
4 0-255 STROBE: 0-15 = OFF, 16-255 = 1Hz – 12Hz
5 0-255 MASTER: 0 = OFF, 1-255 = DIMMER 1-100% OUTPUT
6 0-255
Special functions
0-31 = Inactiv
32-63 = Automatic Dimming (upwards)
64-95 = Automatic Dimming (downwards)
96-127 = Automatic Dimming (upwards / downwards)
128-159 = Automatic colourchase
160-191 = coincidence colour chase, 3 colours
192-223= coincidence colour chase, 7 colours
224-255= start music control
DMX MODE 6 (Compatibility mode)
Chanel Value Fuction
1 0-255 RED: 0 = OFF, 1-255 = DIMMER 1-100% OUTPUT
2 0-255 GREEN: 0 = OFF, 1-255 = DIMMER 1-100% OUTPUT
3 0-255 BLUE: 0 = OFF, 1-255 = DIMMER 1-100% OUTPUT
4 0-255 0 = Off , 1-255 = different colourmacros (36)
5 0-255 STROBE: 0-15 = OFF, 16-255 PULSE, SLOW – FAST
6 0-255
Special functions
0-31 = Inactiv
32-63 = Automatic Dimming (upwards)
64-95 = Automatic Dimming (downwards)
96-127 = Automatic Dimming (upwards / downwards)
128-159 = Automatic colourchase
160-191 = coincidence colour chase, 3 colours
7 0-255 MASTER: 0 = OFF, 1-255 = DIMMER 1-100% OUTPUT
