IIT ShortCam Lite - Product Overview and Features; 1.1. Product Overview; 1.2. Product Features

ShortCam LiteUser Guide
1
1、Product Overview and Features
1.1. Product Overview
ShortCam Lite is a single-light infrared thermal imaging inspection tool for cell phone
motherboard repair, can quickly locate the PCBA short circuit, leakage of faulty components,
support for multi-platform use, can efficiently solve the traditional leakage detection methods
with low efficiency, operational difficulties and other issues.
1.2. Product Features
 High-definition thermal imaging, details are more clear, support one-key speed check
function, fast and accurate positioning of high-temperature device location;
 Equipped with WIFI function, which supports multi-platform client connection such as
iPhone, Android cell phone and laptop;
 Infrared camera is removable, can be mounted on the microscope through a special
bracket, simple operation, multi-purpose;
 Bracket can be flexibly telescoped to adjust the height, easy to store, comprehensively
enhance the user experience, to meet the needs of different scenarios.
Product Specifications
Specifications of Infrared Thermal Imaging Camera ShortCam Lite
Detector type
Uncooled VOx detector
Resolution
256*192
Wavelength range
7.5~13.5 um
FOV
25°*18°
Temperature Measurement Range
-20℃~550℃
Temperature Measurement Distance
5cm~25cm
Temperature Measurement Accuracy
±5°C or ±5% (take maximum)
Interface and Display Functions
Display mode
Whitehot/Hotmetal/Rainbow
Connection Methods
Type-C
Image Storage Formats
JPG
Physical property
Product Size/Weight
116*52*150mm/186 g
Installation
Plug and play, no installation required
Input supply voltage
5V DC
Power wastage
2.5W
Storage temperature range
-20℃~60℃
Working environment
3℃~45℃, 95% relative humidity
