Iiyama ProLite e2200ws - CONTROLS AND CONNECTORS; Front and Back Panel Layout

ENGLISH
FRONT PANEL CONTROL
A Auto Button (AUTO)
B Exit / Volume Button (EXIT)
C Scroll Down / Contrast Button ( )
D Scroll Up / Brightness Button ( )
E Menu / Select Button (ENTER)
F Power Switch ( )
G Headphone Connector
H
Power Indicator
Green: Normal operation
Orange: Power Management
The monitor enters into power management mode which reduces the power
consumption to less than 2W when receiving no horizontal and/or vertical
sync signal.
I
Speakers
J
Audio Connector (LINE IN)
K AC Connector (POWER IN)
L DVI-D 24pin Connector (DVI) *
M D-SUB mini 15pin Connector (D-SUB)
N Keyhole for Security Lock
CONTROLS AND CONNECTORS
You can fasten a security lock and cable to prevent the monitor from being removed
without your permission.
NOTE
6 BEFORE YOU OPERATE THE MONITOR
<Front>
<Back>
NOTE
AUTO
EXIT
ENTER
* Available for ProLite E2200WS only.
