ENGLISH
6 BEFORE YOU OPERATE THE MONITOR
CONTROLS AND CONNECTORS
Power Switch ( ) / Power Indicator
Blue: Normal operation
Orange: Power Management
Select / Input select Button (
)
Scroll up / X-Res Technology Button (
)
Scroll down / i-Style Color Button (
)
Menu Button ( )
Speakers
Headphone Connector (EARPHONE)
HDMI Connector (HDMI2)
HDMI Connector (HDMI1)
DVI-D 24pin Connector (DVI)
Keyhole for Security Lock
You can fasten a security lock and cable to prevent the monitor from being removed
without your permission.
D-SUB mini 15pin Connector (VGA)
Audio Connector (AUDIO IN)
Installation hole of Cable Holder
AC Connector (AC POWER IN)
Main Power Switch (POWER SWITCH)
<Front> <Back>
NOTE
NOTE
