UNO Synth Pro
4 – Front Panel Interface
20
MODULATION SOURCES MODULATION DESTINATIONS
Velocity OFF
Mod Wheel Osc 1 Tune
Aftertouch Osc 1 Wave
Key Pitch Osc 1 Level
Key Gate Osc 2 Tune
Osc 1 Tune Osc 2 Wave
Osc 1 Level Osc 2 Level
Osc 2 Tune Osc 2 FM Amount
Osc 2 Tune Osc 3 Tune
Osc 3 Tune Osc 3 Wave
Osc 3 Level Osc 3 Level
Noise Osc 3 FM Amount
Filter 1 Cuto
Noise level
Filter 1 Res Filter 1 Cuto
Filter 2 Cuto Filter 1 Res
Filter 2 Res Filter 2 Cuto
Filter Spacing Filter 2 Res
LFO 1 Filter Spacing
LFO 1 Fade In LFO 1 Wave
LFO 2 LFO 1 Rate
LFO 2 Fade in LFO 2 Wave
Filter Env LFO 2 Rate
Amp Env Filter 1 Env Amount
CV 1 IN Filter 2 Env Amount
GATE 1 IN Amp Env Amount
CV 2 IN Drive Amount
GATE 2 IN Delay Amount
Accent Reverb Amount
Gate Mod Amount
Tie CV OUT 1
GATE OUT 1
CV OUT 2
GATE OUT 2
Accent Amount
Mod N1-16 Amounts
CV (control voltage)
CV input is bipolar (where value 64 is +2.5V).
CV output is unipolar (positive range only from 0 to +5V).
