Technical data
Design voltage VAC 220 ... 230 ± 10%
100 ... 115 ± 10%
Frequency Hz 50 / 60
Power consumption
W 160
Output power
W 100
Motor speed:
Idle
Under load
rpm
28000
25000
Circumference speed:
Idle
Under load
m/s
76
53
Effective volume:
Grinding container A 11.5
Grinding container A 11.4
ml
80
250
Working time:
Short-time operation
min 1 / 10
(1 min. ON / 10 min. OFF)
Safety Safety switch on the grinding container,
temperature limiter in the motor.
Malfunction display
Orange-red glow lights, display of over-
temperature and grinding area not closed
Drive Universal motor
Parts in contact with product:
Grinding beaker A 11.5 (80 ml)
Grinding beaker A 11.4 (250 ml)
Rotor shaft
Beater A 11.1
Cutter A 11.2
Beater A 11.3
Double beater A 11.6
Filling funnel A 11.7
Stainless steel 1.4571
(outer shell fluoroplastic ETFE)
Stainless steel 1.4571
(outer shell polycarbonate PC)
Stainless steel 1.4571
Stainless steel 1.4034
(hardness approx. 52 HRC)
Stainless steel 1.4112
(hardness approx. 55 HRC)
S
tainless steel 1.4112, wolfram - carbide coated
(core hardness approx. 58 HRC, surface
Titanium (plasma nitrited, surface hardness
1200 HV)
Stainless steel 1.4571/PTFE
Permitted ambient temperature °C + 5 ... + 40
Permitted relative humidity % 80
IP code according to EN 60 529
IP 43
Protection class II
Excess voltage category
II
Contamination level
2
Noise level
dB
max. 85
Operation at a terrestrial altitude
m
max. 2000
Dimensions (W x D x H)
mm
85 x 85 x 240
Weight
kg
1.5
Subject to technical changes!
