IKA A11 basic - Page 2

2
IKA
®
A11 basic
On/Off
On/Off-Taster
Störungsanzeige
On/Off-switch
Malfunction display
Druckrichtung
Pressing direction
Maximale Füllhöhe
Maximum filling height
Fig. 1
Fig. 2
IKA
®
A11 basic
On/Off
Fig. 3
20
Maximale
Füllhöhe
Maximum
filling height
Fig. 5 Fig. 6
On/Off
IKA
®
A11 basic
22
9
8
24
14
13
20
19
11
Item Designation
8 Guard ring
9 O-ring
11 Beater
13 Hexagonal nut
14 Pressure spring
19 O-ring
20 Seal
22 Guide screw
24 Hexagonal nut
