Technical data
Nominal voltage VAC 230 ± 10% / 115 ± 10%
Frequency Hz 50 / 60
Max. input power W 300
Working temperature range °C -20 ... RT
Operating temperature range (with external heating)
°C -20 ... + 40
Temperature stability – internal temperature
control (according to DIN 12876)
K ± 0.1
Temperature control PID
Temperature measurement, absolute accuracy K ± 0.5
Temperature setting Key on the front of the device
Temperature setting resolution K 0.1
Temperature display LED
Temperature display resolution K 0.1
Classication according to DIN 12876-1
Class III (FL) suitable for flammable and non-flammable fluids
Cooling capacity according to DIN 12876
+ 20 °C
+ 10 °C
0 °C
- 10 °C
- 20 °C
W 400
370
320
240
130
Pump speed (adjustable) rpm 1000 ... 3200
Max. pump pressure/suction bar 0.3/0.2
Max. flow rate (at 0 bar) l/min 15
Bath volume I 1.4 – 4.0
Fluid maximum viscosity mm
2
/s 50
Sub-level protection Yes
Interface USB, RS 232
Permitted on-time % 100
Protection class according to EN 60 529
IP 21
Protection class
I
Excess voltage category II
Contamination level 2
Permitted ambient temperature °C + 5 ... + 32
Permitted ambient humidity % 80
Dimension (W x D x H) mm 220 x 525 x 475
Weight kg 28
Operation at a terrestrial altitude m max. 2000
Subject to technical changes!
