Drive unit:
Speed range rpm 500 - 10000
Speed display Scale
Speed variation on
load change % <1
Perm. ambient temperature °C 5 - 40
Perm. humidity % 80
Perm. on time (drive unit) % 100
Protection to DIN EN 60529 IP20
Power consumption W 1100
Power output W 700
Design voltage V AC 230
±10%
or V AC 115 ±10%
Frequency Hz 50/60
Noise level dBA 72 (without disp.
tool)
Viscosity See table, p.22
Dimensions (drive) WxDxH mm 125 x 120 x 367
Dimensions (boom) mm Ø16 / L220
Weight kg 6,1
Contamination level 2
Protection class 2
Overvoltage category II
Operation at a terrestrial m max. 2000 above
altude m sea level
Subject to technical changes!
23
012008
Technical data
