Parts list, rotor head
Parts list, rotor head
Piccolo PRO Order No. 68200
No. off Order No. Description of it em Dimensions
2 67365 Ball clip
1 67366 Swashplate driver 25.5 x 8.5 x 2.5 mm
1 67369 Main rotor centre pi ece 24.3 x 5 x 2.11 mm
2 67542 Blade holder
6 67561 Screw M2 x 6mm
6 67582 Nut M2 mm
2 67583 Self-locki ng nut M2 mm
2 68202 Silicone pr essure piece 1 x 6 mm
1 68204 Annular clamp 2 x 5 mm
1 68205 Ballrace 4 x 7 x 2 mm
4 68206 Flanged ballr ace 2 x 5 x 1.5 mm
1 68207 Bearing retainer ring 1 x 5 mm
1 68208 Steel flybar 2 x 150 mm
2 68209 Flybar lever 2 x 3 x 15 mm
1 68210 Collecti ve pitch actuator ring 11 x 7 x 3 mm
1 68211 Collecti ve pitch sleeve 28 x 22 x 10 mm
2 68212 Collecti ve pitch bellcrank 2 x 7 x 15 mm
1 68214 Rotor head 17 x 45 x 9 mm
1 68215 Rotor head clip 16 x 6.5 x 11 mm
4 68216 Screw M2 x 12 12.8 black
1 68219 Pitch-axis pushr od 1 x 55 mm
1 68220 Collecti ve pitch pushrod 1 x 59 mm
1 68221 Roll-axis pushr od 1 x 45 mm
2 68222 Hiller pus hrod 36 x 2 mm
2 68223 Collecti ve pitch pushrod 14 x 3 mm
1 68224 Collecti ve pitch swashplate
1 68225 Swashplate guide 2 x 6 x 12 mm
2 68239 Rotor blade, symmetr ical section
2 68240 Hiller paddl e
2 68600 Screw M2 x 10 socket cap
2 67566 Ballrace, 2 x 6 x 3 2 x 6 x 3 mm
1 67399 Dowel pin 1 x 8 mm
