Parts list mechanics
Parts list mechanics
No. off Order No. Description of item Dimensions
1 60552 Fan and fan housing 31 x 32 x 10 mm
2 67361 Skid 120 x 10 x 5 mm
1 67362 Tail rotor hous ing 28 x 24 x 20 mm
1 67363 Tail rotor gear 25 Ø x 10.5 mm
1 67376 Tail rotor bl ade 146 x 35 x 10 mm
1 67379 Tail rotor s haft, CFRP 3 Ø x 114 mm
3 67385 Rubber grommet 2 x 5 x 3 mm
2 67396 Washer M 1.4 mm
1 67404 Tailskid 1 Ø x 80mm
1 67403 Tail motor pow er cable set
1 67459 Freewheel 49x14.3mm
3 67588 O-ring 2 x 6 mm
1 67813 Suppressor capacitor 100 nf
1 68218 Servo support 19 x 19 x 8 mm
1 68230 Decal sheet
1 68231 Steel pinion, 10-tooth 6 x 10 mm
1 68255 Steel main rotor shaft Ø 3 x 117.5mm
1 67381 Tail boom, exposed carbon 5 x 320 mm
1 68236 Smoked-tint cabin glazing
1 68238 Pro canopy
1 68241 Horizontal stabili ser, CFRP 80 x 35 mm
1 68242 Vertical stabiliser, CFRP 60 x 56 mm
1 68243 Piccoboard support 45 x 37 x 2 mm
1 68244 Battery holder 46 x 32 x 6 mm
1 68245 Piccolo PRO chassis 110 x 95 x 20 mm
2 68249 Screw M2.6 x 10 mm
1 68251 Piccolo PRO tail m otor 12 x 30 mm
2 68252 Screw M 1.6 x 3 mm
2 68254 CFRP skid bar 2 x 76 mm
1 69050 410 Pro main drive motor 27.5 x 40 mm
5 67388 Silicone sleeve 1 x 1 mm
2 67397 Washer M 2.6
1 67571 Flanged ballrace 3 x 7 x 3 mm, flanged
1 68247 Ballrace 3 x 7 x 3 mm
2 68253 CFRP skid bar 2 x 74mm
2 3-1640 Gold-contact plug / s ocket (2 pairs)
1 68229 Allen key 1.5 mm A/F
1 1238 Cyano-acrylate adhesive 2 gr.
1 67405 Screwdriver set
1 68200.2 Piccolo Pro buildi ng instructions
1 68266 CRP tail support
